*Warranty applies in the USA and Canada only. Contact SECOLARM for details.
Specifications
| Operation | Fail-safe / Fail-secure |
| Contact Switch | NO/NC. |
| Current Draw | 300mA@12VDC, 150mA@24VDC |
| Lock Status Rating | 1A@30VDC |
| Lock status | Micro-switch |
| Operating Voltage | 12/24 VDC |
| Door Status | Reed switch, 10W (Max) |
| Door Status Max Switching Contact | 0.5A |
| Dimensions | 3-1/4” x 1-3/16” x 1-1/8” (82x30x28 mm) |
 |
 |
 |
|
