Description
Altronix DL3 is a 1 second to 1 minute door control timer that is used for basic door operation. This timer, when activated by a momentary or maintained trigger, has an audible indicator.
Specifications
- Input
- 12 volt - 24 volt AC or DC operation.
- Features
- Isolated AC or DC voltage 5V-24V trigger.
- Time adjustable from 1 second to 1 minute.
- Momentary or maintained trigger.
- Audio Indicators
- On-board sounding device.
- Temperature
- Operating 0ºC to 49ºC (32ºF to 120ºF).
- Storage - 20ºC to 70ºC ( - 4ºF to 158ºF).
- Relative Humidity 85% +/- 5%.
Dimensions & Weight
- Dimensions (approximate):
- 1.5"W x 4"L x 0.75"H (38.1 mm W x 101.6 mm L x 19.05 mm H).
- Weights (approximate):
- Product Weight: 0.13 Lbs. (0.06 kg).
- Shipping Weight: 0.15 Lbs. (0.08 kg).
