Alpha AT1000MS 10.0" Touchscreen Video Monitor for AlphaTouch Platform

AlphaSKU: AT1000MS

Sale price$935.00
Usually ships within 3-5 business days
Buying in Bulk? Have Questions?
Call Us: 718-435-2800


PoE, Full Touchscreen Operation with Hands-Free Communication

The Alpha Communications® AT1000MS Series AlphaTouch™ series hands free type 10.0" touchscreen IP color monitors provides the most advanced video-intercom system available, for any size building, with any number of monitors, door stations, and remote cameras. The AT1000MS monitors are SIP-enabled indoor monitor for multi-functional communications. At the core of the AT1000MS series an oversized capacitive touchscreen and intuitive software interface.

These attractive monitors are conveniently mounted right on the wall and only protrude 0.87"! Due to its advanced design and TCP/IP protocol, the AT1000MS does not require any servers, power supplies, switchers, boosters, video distributors, and requires simply a LAN connection and the PoE switch(es).

All AT1000MS monitors feature a crystal clear 10.0" color TFT LCD capacative touchscreen monitor (measured diagonally), electronic call signaling, enhanced echo-cancellation duplex type hands-free voice with door release capability and other functions based on the unit's firmware.

The AT1000MS is a sleek, stylish IP monitor of superior quality, manufactured in anodized aluminum. Its multi-channel capability virtually eliminates busy signals on the system.


  • 10.0" (diagonal) Crystal Clear Color TFT LCD Capacitive Touch Video Screen
  • 1024 x 600 resolution Brightness: 300nits 800:1 Contrast 16M colors up to 720p
  • Uses simple CAT5 / CAT6 LAN wiring and RJ45 connectors - 10/100 Mbps Ethernet
  • Monitors are connected to a PoE switch output or PoE injector (PoE IEEE802.3af)
  • Enhanced Duplex Hands-free Digital Voice Operation with echo canceling processor
  • Easy Installation (surface or optional desk using SOB-UNI adapter)
  • SIP v1 (RFC2543)  SIP v2 (RFC3261) - Static IP or DHCP
  • Rugged and Reliable. Simple to Operate
  • Low profile surface monitor protrudes only 0.87" from wall
  • Intuitive Graphic User Interface (GUI)
  • US or European electrical wall box mounting
  • Call to any concierge station and optional panic call
  • Multi-talkpath system with a simultaneous voice talk path from every door station and concierge station


Screen Size: <10" Diagonal
Aspect Ratio: 16:9
Resolution: 1280x800
Contrast Ratio: 800:1
Viewing Angle:

 ±89° Left, ±89° Right, 89° Upper, ±89° Lower

Touch Type:

Projected Capacitive

Temperature Range:

14° to 112°F (-10° to 45°C)


10% to 90% (non-condensing)

Dimensions: 9.9"W x 7.2"H x 0.87"D (251 x 182.5 x 22 mm)
