Description
8 Megapixel IP Plug & Play, Outdoor Turret, Fixed Lens, Up to 98’ IR Range, True WDR, White Light & Deterrent, Built-in Mic/Speaker, SD Card Slot, 12VDC/PoE
Features
- True AI Human and Vehicle Classification for Line Crossing and Intrusion Detection
- White Light & Deterrent: AI Triggered
- 8 Megapixel Resolution
- Fixed Lens
- True Day/Night with IR Range up to 98’
- Smart IRs
- Ultra H.265,H.265,H.264,MJPEG Compression
- 30 FPS Recording and Live
- WDR
- Micro SD Slot: Up to 256GB
- Built-in Mic
- Built-in Speaker
- IP67 Weatherproof
- 12VDC/PoE Operation
- ONVIF
- Free iOS & Android Apps for Smart Phones & Tablets
- Free Central Management Software (CMS)
- Free MAC Client
Camera |
VIS-P8BXIR28NH-AIWL |
Sensor |
1/2.7", 8.0 megapixel, progressive scan, CMOS |
Lens |
2.8mm@F2.0 4.0mm@F2.0 |
DORI Distance |
Lens (mm) Detect (ft) Observe (ft) Recognize (ft) Identify (ft) |
2.8 275.6(84m) 110.2(33.6m) 55.1(16.8m) 27.6(8.4m) |
|
4.0 393.7(120m) 157.5(48m) 78.7(24m) 39.4(12m) |
|
Angle of View (H) |
112.4° 86.5° |
Angle of View (V) |
60.1° 44.1° |
Angle of View (O) |
146.1° 112.5° |
Adjustment angle |
Pan: 0°~360° Tilt: 0° ~ 90° Rotate: 0°~360° |
Shutter |
Auto/Manual, 1 ~ 1/100000s |
Minimum Illumination |
Colour: 0.01Lux (F2.0, AGC ON) 0Lux with IR on |
Digital noise |
2D/3D DNR |
Day/Night |
IR-cut filter with auto switch (ICR) |
S/N |
>56dB |
F[ Range |
Up to 98 ft (30m) IR range |
Wavelength |
850nm |
IR On/Off Control |
Auto/Manual |
Defog |
Digital Defog |
WDR |
120dB |
Video |
|
Video Compression |
Ultra 265, H.265, H.264, MJPEG |
H.264 code profile |
Baseline profile, Main profile, High profile |
Frame Rate |
Main Stream: 8MP (3840*2160), Max 20fps; 5MP (3072*1728), Max 30fps; 4MP (2560*1440), Max 30fps; 1080P (1920*1080), Max 30fps; |
Sub Stream: 1080P (1920*1080), Max 30fps;720P (1280*720), Max 30fps; D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF(704*288), |
|
Third Stream: D1 (720*576), Max 30fps; 640*360,Max 30fps; 2CIF (704*288), Max 30fps; CIF(352*288), Max 30fps; |
|
Video Bit Rate |
128 Kbps~16 Mbps |
OSD |
Up to 8 OSDs |
Privacy Mask |
Up to 4 areas |
ROI |
Up to 8 areas |
Motion Detection |
Up to 4 areas |
Image |
|
White Balance |
Auto/Outdoor/Fine Tune/Sodium Lamp/Locked/Auto2 |
Digital Noise |
2D/3D DNR |
Smart IR |
Support |
Flip |
Normal/Vertical/Horizontal/180°/90°Clockwise/90°Anti-clockwise |
Dewarping |
Supported |
HLC |
Supported |
BLC |
Supported |
Audio |
|
Audio Compression |
G.711 |
Two-way audio |
Supported |
Suppression |
Supported |
Sampling Rate |
8KHZ |
Storage |
|
Edge Storage |
Micro SD, up to 256GB |
Network Storage |
ANR |
Intelligent |
|
Smart intrusion Prevention |
Cross line, intrusion, enter area, leave area detection; |
Face capture |
Support |
Smart |
|
Basic Detection |
Motion detection, tampering alarm, audio detection |
General Function |
Watermark, IP address filtering, tampering alarm, access policy, ARP protection, RTSP authentication, user authentication |
Network |
|
Protocols |
IPv4, IGMP, ICMP, ARP, TCP, UDP, DHCP, PPPoE, RTP, RTSP, RTCP, DNS, DDNS, NTP, FTP, UPnP, HTTP, HTTPS, SMTP, 802.1x, SNMP, QoS |
Compatible Integration |
ONVIF (Profile S, Profile G, Profile T), API |
Web Browser |
Plug-in required live view: IE9+, Chrome 41 and below, Firefox 52 and below |
Plug-in free live view: Chorme 57.0+, Firefox 58.0+, Edge 16+, Safari 11+ |
|
Interface |
|
Network |
1 RJ45 10M/100M Base-TX Ethernet |
Built-in Mic |
Supported |
Audio Sensitivity |
-32±3dB |
Built-in Speaker |
Supported |
Alarm Light |
Supported |
Certifications |
|
Certifications |
CE: EN 60950-1 UL: UL60950-1 FCC: FCC Part 15 |
General |
|
Power |
DC 12V±25%, PoE (IEEE 802.3af) |
Power consumption: Max 10.5W |
|
Dimensions |
7.5” × 3.0” × 2.9” (191× 75 × 74mm) |
Net Weight |
0.90lb (0.41kg) |
Material |
Metal |
Working Environment |
-22°F ~ 140°F (-30°C ~ 60°C), Humidity: ≤95% RH (non-condensing) |
Strorage Environment |
-22°F ~ 140°F (-30°C ~ 60°C), Humidity: ≤95% RH (non-condensing) |
Surge Protection |
2KV |
Ingress Protection |
IP67 |
Reset Button |
Supported |
