Description
The ENFORCER Elbow RTE Push Plate is designed for easy, accessible entry and exit through public area doors. The Elbow RTE Push Plate features a large button for easy, hands-free operation, a red and green LED status indicator, and two stainless steel faceplates. With an expected operating life of over 100,000 cycles and flexible mounting options, the ENFORCER Elbow RTE Push Plate is the perfect solution for reliable, secure, and accessible entry and exit for schools, hospitals, nursing homes, apartments, and other high-density public spaces.
- Oversized plate for increased visibility and ease of use even when hands are not free
- Low-profile design – only 7/8″ (22mm) thick
- Dual-colored LED indicates status (red – standby, green – triggered)
- Outputs rated 1A@30VDC, 0.5A@125VAC
- Operating life: Over 100,000 cycles (factory tested)
- Operating voltage – 12/24VDC
- 2 Faceplates included
- Momentary SPDT switch
Specifications
| Operating Voltage | 12/24 VDC |
| Current Draw | Standby: 24mA@12VDC, 25mA@24VDC, Active: 45mA@12VDC, 47mA@24VDC |
| Switch Type | Momentary NO/NC/COM (SPDT) |
| Contact Rating | Output 1: 1A@30VDC, 0.5A@125VAC, Output 2: 1A@30VDC, 0.5A@125VAC |
| Contact resistance | 50mΩ Max.(initial) |
| Dimensions | 9-13/16″x3-3/4″x7/8″ (250x95x22 mm) |
| LED Status Indicator | Dual-colored LED (red – standby, green – triggered) |
| Operating Life | 100,000 Cycles (factory tested) |
| Material | Faceplate: ABS Plastic with stainless steel insert, Switch box: ABS Plastic |
| Operating Humidity | 0~95% Non-condensing |
| Operating Temperature | 14°~113° F (-10°~45° C) |
| Weight | 10.2-oz (289g) |
