Aiphone IX-DVF SIP Compatible Flush Mounted IP Video Door Station

SIP Compatible Flush Mounted IP Video Door Station
Vandal Resistant Stainless Steel Faceplate

Need this station with UL Certification? Be sure your model has a UL sticker or contact Aiphone for more details.

FEATURES

• Use SIP to integrate with Cisco Unified Call Manager® and answer calls off-site
• ONVIF® Profile S Compliant
• 802.3af PoE with PoE pass through (802.3at Type 2 PoE+)
• 1.23 megapixel fixed color video camera
• Camera vertical adjustment +15º, 0º, or -8º (manual)
• Capture and store the audio and video of active conversations on a microSD™ card (not provided by Aiphone)
• IP65 rated, weather resistant
• Stainless steel faceplate
• 2 contact outputs
• 6 trigger inputs
• 2-year warranty!

SPECS
Power Source: PoE (IEEE 802.3af class 0)
Power Draw: 5.28 Watts
Camera: ⅓" CMOS 1.23 megapixel
Min. illumination: 5 lux
Audio Codec: G.711 (μ-law, A law), G.722
Video Codec: H.264/AVC, motion JPEG
Protocols: IPv4, IPv6, TCP, UDP, SIP, HTTP, HTTPS, RTSP, RTP, RTCP, IGMP, MLD, SMTP, FTP, DHCP, NTP, DNS
Port Security: IEEE 802.1X
Operating Temp: -40° - 140°F (-40° - 60°C)
Protection Rating: IP65, IK08
Dimensions: 10-7⁄16" H x 5-⅞" W
Mounting: Flush mounted with included back box, or surface mount with the SBX-IDVF Stainless Steel surface mount box
